CHARATERISTICS

This type of machine is designed to realize the functions of up and down synchronized feeding and forward and backward sewing. The special structure of both presser foot going up and down alternately and the sliding bearing used for the lower feeding axis make smooth running and produce uniform and neat stitches with low running noise and long life. It is suitable for sewing of thick and extra-thick materials. The horizontal stand is applied for this type of machine.

Uses

It is suitable for sewing of shoes, sofa, and best for different kinds of container slings, leather cases, flex wheel and tent etc.

Specifications

a. Max. Sewing Speed: 700/min.

b. Max. Pitch of Needles: 15mm

c. Max. Height of Pressure Foot 12 mm (hand); 30mm (foot)

d. Max. Sewing Thickness: 23mm

e. Type of Needle: 8 X 200/230/250/300#

f. Power of Motor: 550W

g. Dimensions of Head: 760 X280 X 540mm

h. Net Weight of Head: 85Kg
